D1/D3: Morimoto XB35 HID Ballast

$57.50

Morimoto

Ballast

Clear

Input Pigtail

Clear

Product Description

Trusted: With distribution exceeding 150,000 units over the last four years; more enthusiasts chose Morimoto over any other aftermarket ballast. Easily filling the shoes of the 3Five units that they replace, the brand new XB35 ballasts excel in every way.



Inspired: Packaged into a more retrofit-friendly design, the new XB’s feature countless elements derived from the most popular OEM benchmarks. As good as they are; even arrogant retrofitters may start second-guessing those bulky, power hungry, exposed-to-the-elements, OE ballasts.



Protected: Their die-cast aluminum shell houses a 100% potted circuit board; eliminating any chance of moisture damage. The AMP SuperSeal three-pin connector from TE Connectivity between the igniter and the ballast ensures the safety of this crucial output.



Compact: Slim 17mm body will mount almost anywhere with their extremely functional and attractive eight-position mounting brackets.



Versatile: If you’re like many of us retrofitters, the setup is always changing and now your ballasts can keep up! Since the output can be unplugged from the ballast, you can easily change from D1/D3 to AMP to D2S or any sequence therein (without the use of unreliable adapters, that is). Likewise, if an igniter does happen to go bad, it can easily be replaced.



Fast, Friendly and Efficient: Power hungry ballasts never work well with tricky CanBus systems, but the new XB35 ballasts consume < 5A on ignition without compromising their reasonably quick warm up speed. That’s much less than Denso, Mitsubishi, FastBright, and the old Morimoto too, which makes their ability to reach full intensity a more efficient process.



Reliable & Smart: The XB35 ballasts are designed to last for 2500 hours and there’s not much that will stand in their way. The matured DSP 2.0 software recognizes outside system faults such as a loose high voltage connection, and after one misfire will cut power rather than potentially self-destruct.



Functional Works of Art: Designed by Artur Saakyan in California, the Morimoto XB35 Ballasts feature gloss piano black paint. Laser etched graphics. Stainless Steel hardware. Color coordinated mounting bracket and TechFlex braided insulation.



Trusted: For over a decade, HID Kit Pros in Bellevue, Washington has been providing customers with the best quality automotive lighting and accessories while backing it up with unbeatable customer service. Every employee at HKP has been trained on our wide selection of products to help suit each and every customers needs. Local? Stop by our showroom and installation center, test out our products in person with our state of the art testing equipment. Have a question? Contact us.



What’s Included

  • Ballast: 1x Morimoto XB35 Computer
  • Output: Morimoto XB D1/D3 Compatible
  • Bracket: Eight Point Stainless Steel
  • Warranty: Two Years

Compatibility

  • Bulbs: All D1S or D3S
  • Vehicles: All with 12-24V electrical systems

Tech Specs

  • Output Wattage: 35W +/- 2%
  • Output Current: 85V AC
  • Ignition Voltage: 23KV
  • Input Voltage: 9-32V DC
  • Input Current: 5A @ Startup
  • Open Circuit: Protected (< 1s)
  • Short Circuit: Protected (< 1s)
  • Climate Range: -40C to +85C
  • Rated Lifetime: 2500 hours (5-7 years)

Additional Information

Weight 0.01 lbs
Shipping Dimensions 6 × 4 × 1 in
Brand

Morimoto

Warranty

2 Years

Shipping

Ships Same Day

Wattage

35 Watt (Standard)
